General performances
Overall length - 19.60 m
Hull length - 19.22 m
Length at waterline - 17.21 m
Maximum beam - 5.60 m
Beam at waterline - 4.77 m
Draft - 2.40 m
Height of mast above water - 23.50 m
Unladen weight - 34.1 t
Displacement of loaded yacht - 38.8 t
Keel - 8.5 t
Mainsail area - 58 m²
Genoa area - 88 m²
Mizzen area - 30 m²
Storm staysail area - 35 m²
Engine - 150 HP
Fuel capacity - 1400 l
Fresh water capacity - 900 l

CONSTRUCTION
• Hull made from Roving 71 glass fibre + glass flakes with anti-osmosis barrier / isophthalic resin composite monolithic laminate
• The bulkheads are made of plywood with foam filler, glued into the hull (as well as wooden partitions, furniture, etc.)
• This system guarantees the highest rigidity of the whole unit and optimises load spread.
• The bulkheads are glued and laminated with the deck. 6 of them are watertight collision bulkheads with isolation valves.
• The fore and aft bridge, foredeck and quarter deck are made from "Amel teak" (the real teak imitation), moulded into the deck.
• Dual circuit hydraulic wheel steering
• The transom opens fully with the dinghy launching platform by hydraulic control.

ENGINE ROOM
• Engine STEYR, 150 hp
• Hydraulic gearbox with shaft brake. AMEL angle transmission
• Self pitching propeller. The rope and net cutter Spurs.
• Diesel fuel capacity: 1400 liters (2 aluminium tanks x 700 liters)
• Two of diesel fuel filters with 3-way tap.
• ONAN generator 19.5 kW (4-cylinder, 2.4 liters, 1500 rpm)
• Retractable bow thruster
• Stern thruster
• Fresh water pumps, hot water tank (40 liters), A/C compressors

SAILS AND ACCESSORIES
• Tri-radial cut Hydranet mainsail
• Tri-radial cut Hydranet mizzen sail
• Tri-radial Hydranet genoa
• Tri-radial Hydranet storm staysail
• Gennaker
• Complete set of sheets and vangs for both booms

RIGGING
• The Amel 64 is rigged as a ketch
• AMEL main and mizzen masts. The finish is two-component polyurethane paint
• AMEL 24V electric roller reefing systems with manual release on both masts
• VECTRAN and DYNEEMA halyards
• 2 carbon booms
• Spinnaker pole with rigging
• RECKMANN electric genoa and storm staysail furling gear

NAVIGATION ELECTRONICS
• FURUNO NAVNET TZT2 radar-plotter with 15" touchscreen (cockpit)
• FURUNO GP33 GPS and GP330 active antenna
• SC 30 I satellite GPS
• B & G HYDRA 5000 navigation system comprising: 1 GFD at the chart table and 1 GFD in the cockpit
• GARMIN VHF at navstation. VHF radio additional handset with loudhailer. Spare antenna for the VHF
• FURUNO FA50 AIS transceiver for TZT2 with VHF antenna
• FURUNO Hub 101, additional b/w display, 2 analogue displays B&G
• Hydraulic autopilot FURUNO NAVPILOT 711C
• Second independent autopilot FURUNO NAVPILOT 711 C
• Meteo station FURUNO Fax30 Navtex weather fax to interface with TZT2. Meteo station NAVTEX NX 300 (FURUNO)
• B&G analog display (wind angle)
• Additional black and white display B&G HYDRA 5000
• Echo sounder DFF1
• Satellite TV
• Second VHF station in cockpit
• GPS chartplotter TZ 14 19" on chart table
• NAVNET TZ 14 in cockpit

DINGHY GARAGE
• Access to the dinghy is from the aft platform when it is open, and from the deck by means of a lockable hatch. This garage is watertight from the inside and the outside when the aft platform is closed.
• Accommodates dinghy/rigid bottom tender
• The entry / exit operation is performed by a remote-controlled electric winch and guide rollers.

DECK EQUIPMENT
• Stainless steel stem fitting, 2 anchor rollers, stainless steel bow protection
• Fresh water connection on the deck
• Stainless steel anchor BUGEL (WASI) 42 kg, 100 meters of stainless-steel chain with a diameter of 12 mm and 30 meters of anchor line with a diameter of 20 mm
• Electric windlass 2000 W, anchor chain counter, cockpit control
• Second anchor set (40 m chain, 60 m anchor line, stainless steel DELTA anchor 32 kg stainless steel)
• Second electric windlass, cockpit control
• 2 electric genoa sheet winches
• 2 electric staysail sheet winches
• 1 electric mainsheet winch
• 1 electric mizzensheet winch
• 2 electric stern winches for mooring
• 2 manual winches at the mast
• 4 halyard downhauls (main and mizzen masts)
• 4 halyard clutches (including one double)
• 1 helmsman's station in the wheelhouse with a black leather covered stainless steel wheel. The wheel steering is hydraulic
• Central console in the wheelhouse for the electronics, together with all the other controls (windlass, furling gear, thrusters, etc)
• Sun awning, covers the entire deck
• Retractable tilting hydraulic gangway
• Additional folding gangway, manually installed on the bow or stern

WHEELHOUSE
• Spacious, comfortable, well-protected wheelhouse. Strong composite material with a metal frame; makes for pleasant life on board, and comfortable and safe sailing in all weather
• Panoramic view, excellent natural ventilation
• Windshield wipers with washers
• Electrically driven rigid sliding sun awning

ELECTRICAL INSTALLATION
• 24V and 220V distribution boards with ammeters and voltmeters
• 12V circuit for engine and generator (1 x 90 Amp/h battery for each)
• 24V service circuit: set of batteries for a total of 800 Amp/h, of which 200 Amp/h are dedicated to the bow thruster, windlass and sail furlers
• 220V circuit with shore power socket and cable
• 2 chargers x 24 V, 100 A + 1 charger 24 V, 60 A (for the bow thruster)
• Inverter 24/24, 20 A
• Inverter 24/220 V, 5000 W + 1 converter 24/220 V, 800 W (dedicated to HI-FI, TV and computer)
• LED lighting (blue) on the deck and on the aft platform
• LED spotlights on the main and mizzen masts

INTERIOR
• 3-cabin version with three bathroom/heads
• Wood trim - American walnut varnished with several layers of two-component polyurethane gloss varnish
• natural teak flooring; Bolon floor in the galley
• Many handrails, direct and indirect lighting
• Curtains on all the port lights
• Black-out blinds and fly screens for all hatches

Watermaker 220 V, 240 l/h
WEBASTO air heating system for the entire yacht
Air conditioning 220 V
Removable carpet in all cabins
Toilets with electric pumps and black water tanks
MIELE washing machine with dryer (in the aft bathroom on the starboard side)
A set of soft cushions with backrests in the cockpit
A set of mattresses on the aft deck
Winter awning for the cockpit
TV in the saloon

Galley:
• 4-burner gas stove
• Electric hood with filter
• Stainless steel microwave oven, with grill, 220V, Miele
• Dishwasher
• Refrigerator 180 liters and freezer compartment 130 liters
• Fresh water capacity: 2 x 450 liters tanks
• Wastewater tank (capacity 120 liters) with two sewage pumps

Dinghy HIGHFIELD 340 (with aluminum floor)
Outboard engine YAMAHA 20 h.p.
Liferaft ZODIAC for 8 pax, in container
